AIC for Thailand

AIC

02/25

Effective from 08 MAY 2025

to UFN

Published on 01 MAY 2025

  PLANNED ESTABLISHMENT OF NEW TAXIWAYS AND NAVIGATION AIDSAT SUVARNABHUMI INTERNATIONAL AIRPORT

1  INTRODUCTION

1.1 This AIC presents information on the planned establishment of new taxiways and navigation aids at Suvarnabhumi International Airport.
1.2 This AIC will be followed up with an AIRAC AIP Amendment or AIP Supplements that will provide the relevant details for aircraft operators.

2  DESCRIPTION

2.1 Runway 02L/20R is part of the Suvarnabhumi Airport Development Master Plan initiated by Airports of Thailand Plc. (AOT).
2.2 To accommodate anticipated air traffic growth and reduce airborne and ground delays, the airport management has planned the implementation of runway 02L/20R along with its associated taxiways, including a perimeter taxiway F13 extending from the southern end of parallel taxiway F to connect with taxiway D, bypassing runway 02R/20L.
2.3 In addition, there are plans for the establishment of ILS for runway 02L/20R and SVB DVOR/DME.

3  PLANNED IMPLEMENTATION SCHEDULE

The operation will be carried out as follows:

2025: Perimeter taxiway F13 and taxiway D extension

- Perimeter taxiway F13, extending the southern part of the parallel taxiway F and connecting taxiway F to taxiway D (see Figure 1),
is planned to be established to allow aircraft to reach the apron without crossing runway 02R/20L.


Figure 1 Perimeter taxiway F13 and taxiway D extension locations

2026: ILS system for runway 02L/20R

- Runway 02L/20R is planned to be operated as a category II precision approach runway with the availability of the ILS system and the implementation of new IACs.

2028: SVB DVOR/DME

- SVB DVOR/DME is planned to be re-established at a new location in 2028 following its temporary suspension starting in 2024.

4  TRIAL OPERATIONS

Subsequent trial operations may be conducted to ensure safe and efficient operations.

5  CONTACT

For further information contact via the following:

5.1 Unit: Aeronautical Information Service Sub-Division of Suvarnabhumi International Airport

Tel.: +662 132 6931-4

Mobile: +666 2598 0608

E-mail: [email protected]

5.2 Unit: Air Traffic Navigation Systems Engineering Department, Aeronautical Radio of Thailand Ltd.

E-mail: [email protected]

6  VALIDITY

This AIC cancelled AIC 08/24 and will remain current until further notice.
